Klüber

Klüber POLYLUB GLY 501

Special synthetic lubricating greases for a wide application range

Application Klüber POLYLUB GLY 501

Vehicles Gearshift linkages, moving parts of the heating and ventilation system, shock absorber seals, tie rod elements, seat mechanisms, sun roof guides, pedals. Plain bearings Many types of plain bearing designs. POLYLUB GLY 151, 501, 801 prevent stick-slip to a large extent, particularly in applications where normally a hydrodynamic lubricating film cannot form. Gears Small electric gears with plastic-metal friction components, manual gears operating at very low sliding speeds. Pneumatic installations Pneumatic valves and cylinders with and without piston rod (for these applications, the upper service temperature should not exceed 130 °C). Seals Lubricating and sealing grease for various types of seals. The POLYLUB GLY 151, 501 and 801 lubricants are also suitable for many other plastic components subject to wear caused by relative movement against metal or plastic surfaces. Owing to good damping properties, especially of POLYLUB GLY 801 and 501, noise is considerably reduced.

Klüber ISOFLEX TOPAS L 152

Rolling bearing grease for a wide service temperature range

Application Klüber AISOFLEX TOPAS L 152

Application ISOFLEX TOPAS L 152 is used for rolling bearings, e.g. in electric motors where smooth running is required and a wide range of temperatures is to be covered, e.g. in traction motors. The grease can also be used for the main bearings in wind power stations and plastic/plastic or plastic/steel friction points. Axlebox bearings with line contact, e.g. railways. Applications requiring low starting torques at low temperatures.

Klüber TABURAGS NBU 12 Altemp

Lubricating grease for plain and rolling bearings

Application Klüber TABURAGS NBU 12 Altemp

STABURAGS NBU 12 ALTEMP is used as a grease for rolling and plain bearings and for assembly purposes. It is suitable for slideways, threaded spindles, bearing seats and clamping chucks.

Klüber Lamora HLP 32

Hydraulic oils acc. to DIN 51524 part 2

Application Klüber Lamora HLP 32

LAMORA HLP have been designed for use as hydraulic oils.

Klüber Lamora HLP 46

Hydraulic oils acc. to DIN 51524 part 2

Application Klüber Lamora HLP 46

LAMORA HLP have been designed for use as hydraulic oils.

Klüber Lamora HLP 68

Hydraulic oils acc. to DIN 51524 part 2

Application Klüber Lamora HLP 68

LAMORA HLP have been designed for use as hydraulic oils.

Klüber Klüberoil 4 UH1-32 N

Synthetic gear and multipurpose oil for the food-processing and pharmaceutical industries

Application Klüber Klüberoil 4 UH1-32 N

Klüberoil 4 UH1 N was developed for the lubrication of spur, bevel and worm gears subject to high loads, bearings, spindles, joints as well as lifting, drive and transport chains.

Klüber Klübersynth CHM 2-100

High-temperature oils for transmission, lifting and conveyor chains

Application Klüber Klübersynth CHM 2-100

Klübersynth CHM 2 oils are suitable for transmission, lifting and conveyor chains up to approx. 250 °C in the following industries: conveyors e.g. surface coating, metal coating, white goods, furniture; drying installations e.g. rock wool or gypsum board manufacture

Klüber SUNIT LO/F

For magnetic steel sheets and thin sheets

Application Klüber SUNIT LO/F

SUNIT 006 and SUNIT LO/F can be used for punching sheets made of steel, aluminum and copper alloys. Some typical applications are: punching of magnetic steel sheets;punching of generator and transformer sheets, and of sheets for electric components; punching of profiled sheets; auxiliary for embossing and bending; punching and forming of automobile radiator components; auxiliary for the manufacture of steel sheet drums; auxiliary for the rolling forming of e.g. house facades made of aluminum and steel sheet

Klüber Klüberpharma UH1 4-460

Special synthetic lubricating oils for the pharmaceutical industry

Application Klüber Klüberpharma UH1 4-460

Klüberpharma UH1 4-220/4-460 oils are used for the lubrication of the upper and lower punches and bronze guides in tablet presses. Material / friction combinations: Upper punches made of hardened steel (e.g. 1.23.63) operating against cast iron (e.g. GGG 40). Guide rails made of bronze (e.g. 2.0980.03) Lower punches made of hardened steel (e.g. 1.23.63) operating against cast iron (e.g. GGG 40).

Klüber Klüberfood NH1 CH 6-120 SUPREME

High-temperature chain oil for the food-processing and pharmaceutical industries

Application Klüber Klüberfood NH1 CH 6-120 SUPREME

This product can be used for the lubrication of transport chains of industrial ovens in the food processing industry operating at very high temperatures, e.g. plate carrier chains in baking ovens commonly found in bread, tortilla and pizza production lines.

Klüber UNISILKON GLK 112

Special grease for Bowden cables, seals and plastics

Application Klüber UNISILKON GLK 112

UNISILKON GLK 112 is primarily used for the lubrication of rubber/metal, plastic/metal or plastic/plastic friction pairings. Possible applications are in slideways, seals (also EPDM), Bowden cables. In such applications, UNISILKON GLK 112 reduces friction, prevents squeaking noises and forms a protective layer against atmospheric attack on rubber and plastics. UNISILKON GLK 112 can be used in many components where lifetime lubrication is required.

Klüber Klübertop TG 05 N

Thermosetting bonded coating

Application Klüber Klübertop TG 05 N

Klübertop TG 05 N reduces friction and wear in metal/metal and metal/plastic sliding components. Owing to its structure, Klübertop TG 05 N is particularly suitable for applications in humid environments. It can also be used in context with oil lubrication, e.g. on pistons and other engine components, and in similar fields of application. As a dry lubricant it is suitable for a wide range of components used in bearings, electrical engineering, precision engineering and in textile machines, where contamination by oil or grease should be avoided. Klübertop TG 05 N has also proven effective, especially in terms of corrosion protection, when exposed to high temperatures, extreme environmental conditions (impact of dust, dirt, etc.), and oscillating movements.

Klüber Klübercut CO 6-102

Metalworking oil

Application Klüber Klübercut CO 6-102

The emphasis of application is in the range of easy to medium cutting processes, e.g. in – drilling and boring – milling – sawing. Klübercut CO 6-102 is suitable for a number of metals, particularly for – Al and Al alloys – nonferrous metals but also for – steels – composite materials. As Klübercut CO 6-102 is used undiluted, only a very small quantity is required on the friction point, i.e. the point of contact between the tool and the workpiece. Micro-dosing constitutes a technical progress in the direction of environmental compatibility. The advantages include: – only minute oil residue remains on the swarf; the swarf can be directly transferred to the scrap cycle and be re-used; – no disposal of coolants, no separation and disposal of used emulsions; – clearly improved working environment; almost dry machines and components, less oil mist or oil vapour; – improved tool life and surface quality; the undiluted metalworking oil reduces friction and heat generation.

Klüber Klüberoil GEM 1-68 N

High-performance gear and multipurpose oil based on mineral oil with KlüberComp Lube Technology

Application Klüber Klüberoil GEM 1-68 N

Klüberoil GEM 1 N was specially developed for the lubrication of spur, bevel, hypoid and planetary gears that are subject to high loads. Such gears are frequently used in the steel, mining and sugar industries. It is also used for the lubrication of standard worm gears as defined in DIN 3996. Klüberoil GEM 1 N can also be used for the lubrication of plain and rolling bearings, all kinds of toothed couplings, chains, guideways, joints, spindles and pumps.

Klüber PETAMO GY 193

Tried-and-tested grease for the high-temperature and long-term lubrication of rolling bearings

Application Klüber PETAMO GY 193

Depending on the service temperature, PETAMO GY 193 can be used for lifetime lubrication or relubrication. Experience has shown that lifetime lubrication is possible with temperatures below 150°C, for example in electric motors, fans, carrier and guide rollers, chain wheels, sealed or capped rolling bearings. In relubricatable rolling bearings subject to very high temperatures the grease can be used up to 180°C (e.g. in driers). PETAMO GY 193 should be selected primarily for lubrication of bearings with point contact loading, but can also be used for bearings with linear contact loading and a high share of sliding friction, e.g. cylindrical roller bearings or tapered roller bearings.

Klüber Summit PS 400

Semi-synthetic air compressor oils for oil change intervals up to 5,000 operating hours

Application Klüber Summit PS 400

Klüber Summit PS oils have been especially designed for the lubrication of screw-type and reciprocating piston compressors. They are used for oil change intervals up to 5,000 operating hours in oil-injected screw-type compressors. Klüber Summit PS oils can be used for compressors that were previously run with conventional mineral oils. These oils are neutral towards most elastomer seals used in air compressors, therefore leakage is not to be expected. Klüber Summit PS oils are used for compressors which do not achieve the desired maintenance intervals when using mineral oils and where the use of fully synthetic oils would be uneconomical due to ingress of contamination or a low number of operating hours per year. Klüber Summit PS 100 can also be used for the lubrication of turbocompressors, whereas Klüber Summit PS 300 and 400 have been especially developed for reciprocating piston compressors. Klüber Summit PS oils offer good oxidation stability due to the synthetic base oil content, thus minimising oxidation residues in the compressors and extending oil change intervals and the service life of oil filters and separators. Special inhibitors contained in the oil keep the inside of compressors clean and ensure a high efficiency.

Klüber Unisilkon GLK 1301 DMF

Highly viscous damping grease

Application Klüber Unisilkon GLK 1301 DMF

UNISLKON GLK 1301 was developed as a damping grease for two-mass flywheels serving to eliminate vibrations as are caused, for example, by the imbalanced rotation of internal combustion engines. UNISILKON GLK 1301 is used with the material combinations plastic / plastic, plastic / metal or metal / metal.

Klüber ISOFLEX TOPAS NCA 5051

Synthetic long-term grease

Application Klüber ISOFLEX TOPAS NCA 5051

Owing to its good low-temperature characteristics, ISOFLEX TOPAS NCA 5051 is used in plain bearings in the automotive industry. It is also used to solve lubrication problems in control elements of the fuel feed and ignition system. ISOFLEX TOPAS NCA 5051 reliably protects small adjustment gears against wear throughout their service life. It ensures constant and low breakaway torques. The characteristics make ISOFLEX TOPAS NCA 5051 especially suitable for the lubrication of seals in pneumatic installations.

Klüber STABURAGS NBU 12 MF

High-performance lubricating greases for the long-term lubrication of rolling and plain bearings

Application Klüber STABURAGS NBU 12 MF

STABURAGS NBU 4 MF has proven successful for the lubrication of high-speed rolling bearings in rolls, spindles, cam rollers and tensioning rollers. The grease is also used for bearings in compressors and deep drilling machines. STABURAGS NBU 12 MF is used for highly loaded bearings, e.g. joints, spline shafts, couplings as well as pumps and electric motors, for example in wood drying chambers. Both greases are also suitable for steel-on-steel material combinations in slideways and plain bearings.
